JLG 34HA Parts Manual - Manual (Page 187)

3120804 5-7
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-3. LIFT (BOOM) CYLINDER ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1681840 LIFT CYLINDER ASSEMBLY Ref 10
1 1681841 Rod Weldment 1
1A 0960946 Bushing, Garmax 2
2 1681844 Barrel Weldment 1
2A 0960946 Bushing, Garmax 2
3 1120340 Cap 1
4 1681843 Head 1
5 3480102 Piston 1
6 3300281 Nut 1
7 4563769 Spacer 1
8 4640634 Valve, Holding 1
9 Kit Wiper 1
10 Kit Seal, Rod 1
11 Kit Seal 1
12 Kit Ring, Wear 1
13 Kit O-Ring 1
14 Kit Ring, Guidelock 2
15 Kit Seal 2
16 3900170 Set Screw 3/8”-16NC x 3/8” 1
17 3900141 Set Screw1/4”-20NC x 3/8” 1
18 0100011 Loctite #242 (Not Shown) A/R
19 2200222 Plug 1
20 2200233 Plug 4
21 0100020 Loctite (Not Shown) A/R
22 2160001 Fitting, Grease 1
23 0100035 Thread Locking Compound (Not Shown) A/R
24 0100038 Primer, Locking (Not Shown) A/R
25 2180380 Plug, Orifice Fitting 1
26 0900019 Loctite (Not Shown) A/R
27 2160003 Fitting, Grease 1
— — — — — — — — — —
2901102 Seal Kit (Includes Items 9-15) 1
