SECTION 1 FRAME
.
FIGURE 1-4. DRIVE HUB ASSEMBLY
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
DRIVE HUB ASSEMBLIES
Ref.
2780169
2WD Gas & Diesel
Ref.
2780168
2WD Electric
Ref.
2780167
4WD (Rear)
Ref.
1
7000206
Coupling
1
Hub - Spindle Sub-Assembly
2
7001997
Spindle
1
3
7001998
Seal
1
4
Kit
Cone, Bearing
1
5
Kit
Cup, Bearing
1
6
7007697
Bolt, Wheel
9
7
7000242
Plug, Pipe
2
8
7007601
Hub
1
9
7000257
Cup, Bearing
1
10
7000258
Cone, Bearing
1
11
7000232
Spacer
1
12
7000229
Ring, Retaining
1
13
7000246
Gear, Internal
1
14
Input Shaft Assembly Options: (See Items 201-204 for
Breakdown)
1
15 to 17
Not Used
18
7000253
Washer, Thrust
1
19
Spacer Options:
1
7000252
Drive Hub Assemblies - 2780169 & 2780168
7007653
Drive Hub Assembly - 2780167
20
Gear, Input Options:
1
7000251
Drive Hub Assembly - 2780169
7000201
Drive Hub Assembly - 2780168
7007652
Drive Hub Assembly - 2780167
21
7007654
Spacer (Drive Hub Assembly - 2780167 Only)
1
Carrier Assembly Options:
1
7000247
Drive Hub Assemblies - 2780169 & 2780167
7000202
Drive Hub Assembly - 2780168
22
7001931
Carrier
1
23
7001911
Shaft
3
24
7001913
Pin, Roll
3
25
7001985
Washer, Thrust
6
26
7001909
Roller, Needle
96
27
7000263
Spacer
3
28
Gear, Cluster Options:
3
7001912
Drive Hub Assemblies - 2780169 & 2780167
7007643
Drive Hub Assembly - 2780168
29
7000230
O-Ring
2
30
Gear, Ring Options:
1
7000248
Drive Hub Assemblies - 2780169 & 2780167
7000203
Drive Hub Assembly - 2780168
31
7000253
Washer, Thrust
1
