8-4 3120804
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
20 Decal - Electrocution Hazard Options: 1
1700580 Prior to March 1994
1702292 March 1994 to Present
21 3252347 Nameplate - Footswitch (Prior to June 1992) 1
(was p/n 3251766)
22 3820001 Rivet 4
23 Decal - No Hands Options: 2
1700476 Prior to March 1994
1702294 March 1994 to Present
24 Decal - Attach Lanyard Options: 2
1700477 Prior to March 1994
1702512 March 1994 to June 1995
Use 1704277 June 1995 to Present (was p/n 1702612)
25 0961127 Bushing, Snap 1
26 4751400 Flatwasher 1/4” 6
27 3311405 Nut 1/4”-20NC 5
28 1060279 Cable, Lanyard 1
29 0641408 Bolt 1/4”-20NC x 1” 1
30 1700756 Decal - ADD/Full 1
31 0100010 Loctite #242 (Not Shown) A/R
32 Decal - Fuel Options: 1
1700428 Brown - Diesel
1700430 Brown - Gas
1701542 Dual Fuel
33 Decal - LP Options: 1
1700429 Brown
1701543 LP Gas Only
34 3252356 Decal - Dual Fuel Only 1
35 Decal - LP Options: 1
1700582 Prior to March 1994
1702293 March 1994 to Present
36 1700818 Decal - LP Gas Liquid Withdraw System 1
37 Decal - Hydraulic Oil Options: 1
1700419 Prior to April 2000
1701504 April 2000 to Present
38 Decal - Caution Options: 2
1700460 Prior to March 1994
1702280 March 1994 to Present
39 Not Used
40 1702282 Decal - Warning (March 1994 to Present) 1
41 1702631 Decal - Bar Code 1
42 1702688 Decal - 500Lbs. Max. Capacity 2
0251241 CAPACITY DECAL PLATES INSTALLATION - 265KG
(FRENCH SPEC) (NOT SHOWN) Ref. B
101 9983243 Decal - 265kg (Located on Platform Console Box) 1
102 3820001 Rivet 4
FIGURE 8-1. DECALS INSTALLATION - STANDARD (PRIOR TO JULY 1991) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
