3120804 8-7
SECTION 8 DECALS
S
E
C
T
I
O
N
8
D
E
C
A
L
S
FIGURE 8-2. DECALS INSTALLATION - STANDARD (JULY 1991 TO PRESENT)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
DECAL INSTALLATIONS
0252254 Brown Ref. 4
0252255 Black Ref. 4
0257854 Australian Spec - Brown Ref. 2
1 Decal - 34HA Options: 2
1701471 Brown
1701593 Black
2 to 3 Not Used
4 1701529 Decal - Arrow 4
5 Decal - Stripping Options: 6.49m
1701703 Brown
1701334 Black
6 Decal - JLG Lift Options: 2
1701441 Brown
1701550 Black
7 1701518 Decal - Crushing 6
8 to 10 Not Used
11 3251813 Decal - Made in USA (Prior to July 1995) 1
12 Decal - JLG 2
1700981 Brown
1701321 Black
13 0860520 Box Manual Storage 1
14 1701509 Decal - Operations, Safety & Maintenance 1
15 Not Available Nameplate - Manufacturer 1
16 1700584 Decal - Patent 1
17 Not Used
18 1701500 Decal - Lift Here 4
19 1702300 Decal - Tie Down 4
20 to 21 Not Used
22 3820001 Rivet 4
23 Not Used
24 1702612 Decal - Lanyard Attach (Australian Spec Only) 2
25 0961127 Bushing, Snap 1
26 4751400 Flatwasher 1/4” 6
27 3311405 Nut 1/4”-20NC 5
28 1060279 Cable, Lanyard 1
29 0641408 Bolt 1/4”-20NC x 1” 1
30 1701502 Decal - Hydraulic Oil Level (High) 1
31 0100010 Loctite #242 (Not Shown) A/R
32 Decal - Fuel Options: 1
1701542 Euro - Diesel
1701505 Australian Spec - Diesel
33 1701543 Decal - LP 1
34 3252356 Decal - Dual Fuel Only 1
35 Not Used
36 1700818 Decal - LP Gas Liquid Withdraw System 1
