3120804 5-19
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-9. CYLINDER BELLOWS INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0250635 BELLOWS INSTALLATION - 2WD MACHINES WITH
FIXED AXLE AND 2M FRAME Ref. D
1 0460093 Bellows, Cylinder (Upper & Lower Lift Cylinder) 2
2 Not Used
3 0460084 Bellows, Cylinder (Upper Slave) 1
4 0460082 Bellows, Cylinder (Steer) 2
5 1320037 Clamp 2
6 1320122 Clamp 3
7 Not Required
0250636 BELLOWS INSTALLATION - 2WD MACHINES WITH
OSCILLATING AXLE AND 2M FRAME Ref. D
1 0460093 Bellows, Cylinder (Upper & Lower Lift Cylinder) 2
2 Not Used
3 0460084 Bellows, Cylinder (Upper Slave) 1
4 0460082 Bellows, Cylinder (Steer) 2
5 1320037 Clamp 4
6 1320122 Clamp 3
7 0460083 Bellows, Cylinder (Lockout) 2
0254098 BELLOWS INSTALLATION - 2WD MACHINES WITH
OSCILLATING AXLE AND 1.75M FRAME Ref. C
1 0460093 Bellows, Cylinder (Upper & Lower Lift Cylinder) 2
2 Not Used
3 0460084 Bellows, Cylinder (Upper Slave) 1
4 0460073 Bellows, Cylinder (Steer) 1
5 1320037 Clamp 2
6 1320122 Clamp 4
7 0460083 Bellows, Cylinder (Lockout) 2
0254099 BELLOWS INSTALLATION - 2WD MACHINES WITH
FIXED AXLE AND 1.75M FRAME Ref. B
1 0460093 Bellows, Cylinder (Upper & Lower Lift Cylinder) 2
2 Not Used
3 0460084 Bellows, Cylinder (Upper Slave) 1
4 0460075 Bellows, Cylinder (Steer) 1
5 Not Required
6 1320122 Clamp 4
7 Not Required
