LED Indicator
TECHNICAL SPECIFICATIONS
T=25°C unless otherwise specified.
BOOM LIFT MODELS X17J
JLG
104 X17JR0420113
Colour Description
Red steady Current delivered between 12.5 and 25 A
Red flashing Current delivered between 6 and 12.5 A
Orange steady Current delivered less than 6 A
Orange flashing (4s ON – 1s OFF) Standby phase awaiting restart
Orange flashing (1s ON – 1s OFF) Alarm
Description Symbol Test conditions
Value and/or
Range
Unit
Single‑phase power supply voltage Vin ‑ 230 ± 10% Veff
Frequency f ‑ 50 ÷ 60 Hz
Maximum current drawn per phase
Ifmax P = Pmax
15 Aeff
Initial current peak ‑ Vin=230Veff < 3 A
Power factor cosφ P = Pmax 0,66 ‑
Minimum power consumption Pinmin End of charge < 10 W
Maximum power consumption Pinmax P = Pmax 2,2 kW
Output current I ‑ 25A A
Output voltage U ‑ 48V V
Maximum power supplied Pmax U = U1, I = I1 2000 W
Operating temperature range ΔT ‑ da ‑20 a +50 °C
Maximum relative humidity RH ‑ 90% ‑
Switching frequency fc ‑ 70 ± 10% kHz
Efficiency η
Every operating con‑
dition
90% ‑
Maximum dimensions a×b×c
Without connection
cables
250Ч220Ч90 mm
