6.7 R
ECHARGING THE BATTERY
To check the battery charge, always use the special indicator shown on the display on the
remote control.
The batteries can be recharged even when using the machine (obviously the recharging times
in this case will be longer). The batteries can be recharged even when they are not comple‑
tely down.
If the charge is less than 20% an audible warning signal
will be activated whenever the electric motor is started,
to warn the user to charge the machine.
If the charge is less than 10%, in addition to the audible
warning signal, reduced speed is activated and an icon
comes on in position 4.
To start recharging the battery simply connect the main
power supply to the socket on the right of the undercar‑
riage distributor support and close the circuit breaker.
After a few seconds the charge indicator located on the
right‑hand side of the machine near the battery pack
(see figure) turns red, meaning the battery has started
recharging.
If the machine is on, the display on the remote control
also shows the machine recharge indicator.
