20
M1353-0050  Excella ®
E-25/E25R Classic Incubator Shakers Operating Manual
Figure 4b: Clamp Fastener

NOTE:
The upper girdle secures the flask within the clamp, and the bottom girdle
keeps the flask from spinning.
New Brunswick flask clamps are used on a variety of shaker platforms. Flat head screws
of different lengths and thread pitch are used to secure the clamp, and all types are
provided when you purchase clamps. To identify the proper screw for your shaker
application by reference to the head style, consult Table 1 below, find the proper screws
and set the others aside:
Table 1: Clamp Hardware Application Chart
No matter what size the clamp, use these screws to fasten them to your platform:
Description Part Number Qty. Application
10-24 x 7.9 mm (5/16 in)
flat Phillips (+) head
screw S2116-3051 1 7.9 mm (5/16 in) thick
aluminum, phenolic and
stainless steel
platforms.
5.3 Electrical Connections
Before making electrical connections, verify that:
 the power source voltage matches the voltage on the
ELECTRICAL SPECIFICATION
PLATE , located on the rear panel (see Figure 5 on the following page)
 the
ON/OFF SWITCH , located on the right side panel as you face the front of the
shaker (see Figure 2), is in the OFF position.
Connect the
POWER CORD to the POWER CONNECTOR on the rear panel (see Figure 5)
and the other end to a suitable, grounded receptacle.
