4.1 Front Panel
The keypad on the top (front) panel is the primary user interface to command the Excella
E-10. This section will acquaint you with the keypad’s user interface keys, LED display,
status indicators and function indicators.
Figure 2: Front Panel
Figure 2a: Keypad
1 Keypad 4 LED display
2 ON/OFF switch 5 Function indicators
3 Status indicators 6 User interface keys
6
4 3
5
1
2
