5 Operation
18
ThermoStat plus — Operating Manual
5.2.1 Exchangeable thermoblocks for micro test tubes
1. Place the exchangeable thermoblock (2) on the thermosocket with both flat edges and the
writing facing the front.
2. Tighten the captive screws (1).
5.2.2 MTP exchangeable thermoblock
1. Insert the short screws in the MTP exchangeable thermoblock with the flat washers.
2. Secure the screws from below using the lock washers.
The lock washers prevent the screws from falling out of the bores if the exchangeable
thermoblock is not fixed on the unit.
3. Place the MTP thermoblock on the device in such a way that the spring plate is to the front
left.
4. Tighten the screws.
WARNING!
Caution! Microplates melt at extremely high temperatures.
 Only heat microplates made of polystyrene to a maximum 70 °C.
