Installation
Top Buret ™
English (EN)
4 Installation
4.1 Mounting the device
Abb. 4-1: Top Buret
Fig. 4-1: Top Buret
1 Control panel
2 Discharge tube
3 Canula holder
4 Canula arm
5 Knurled nut
6 Discharge valve toggle
7 Discharge valve
8 Recirculation tube
9 Telescopic aspirating tube
10 connection opening
11 Bottle thread
12 Valve head
13 Air vent cover
14 Dispensing wheels
Top Buret H
2
1
14
13
10
11
12
8
9
7
5
6
3 4
