CellTram® Air · Oil · vario — Operating manual
8
2.1.4 Universal capillary holder
Abb. 5:Universal capillary holder
Fig. 5: Universal capillary holder
2.1.5 Grip head
Abb. 6:Grip head 0 with O-rings and sealing washer
Fig. 6: Grip head 0 with O-rings and sealing washer
The transparent grip head allows the user to visually monitor the position of the capillary.
The capillary is fixed in the universal capillary holder via the grip head.
2.1.6 Adapter for Femtotips
Abb. 7:Adapter for Femtotips with spare O-rings
Fig. 7: Adapter for Femtotips with spare O-rings
1 Barb 2 Rear knurled screw
3 Tension piece 4 Front knurled screw
5 Grip head 0 for capillaries with an outer
diameter of 1.0 to 1.1 mm
1 2 3 4 5
