Installation
FemtoJet ® 4x
English (EN)
23
4.4 Connecting the Microinjector
Prerequisites
• The external compressed air supply is connected.
• Electrical connection data according to the name plate.
• The Microinjector is switched off.
Connect the mains/power cord.
4.5 Connecting an external device
The following devices can be connected to the Microinjector:
• Micromanipulator (InjectMan 4, TransferMan 4r or InjectMan NI 2)
• Computer
4.5.1 Connecting a micromanipulator
Prerequisites
• Y-cable FJ4 is available.
• The Microinjector is switched off.
• The micromanipulator is switched off.
1. Connect the Y-cable to the MANIPULATOR port.
2. Connect the micromanipulator to the Y-cable.
3. Switch on the Microinjector.
The initialization phase starts.
After completion of the initialization phase, the main screen appears.
4.5.2 Connecting the PC
Prerequisites
• Y-cable FJ4 is available.
• Devices are switched off.
1. Connect the Y-cable to the MANIPULATOR port.
2. Connect the computer to the Y-cable.
3. Switch on the Microinjector.
The initialization phase starts.
After completion of the initialization phase, the main screen appears.
The operation is described in the manual for the micromanipulator.
Control with a PC is described in the Cell Technology · PC Control manual.
