Installation
FemtoJet
® 4x
English (EN)
22
4.3.3 Connecting the compressed gas cylinder
Prerequisites
• Quick coupling (from brass) is mounted to the pressure reducer.
• The valves on the compressed gas cylinder are closed.
• The Microinjector is switched off.
1. Connect the pressure tube to the compressed gas cylinder.
2. Connect the pressure tube to the Microinjector.
3. Open the pressure reducer.
4.3.4 Connecting the compressed air supply by the domestic services
Prerequisites
• Quick coupling (nickel plated) is mounted.
• The Microinjector is switched off.
1. Connect the pressure tube to the pressure supply of the domestic services.
2. Connect the pressure tube to the Microinjector.
3. Open the compressed air supply.
CAUTION! Material damage due to contaminated compressed air or
compressed gas
Compressed air containing oil or contaminations will damage the valves and
sealings in the Microinjector.
Only use oil-free, clean and dry compressed air.
Only use cleaned compressed gas (e.g. nitrogen gas).
CAUTION! Material damage due to contaminated compressed air or
compressed gas
Compressed air containing oil or contaminations will damage the valves and
sealings in the Microinjector.
Only use oil-free, clean and dry compressed air.
Only use cleaned compressed gas (e.g. nitrogen gas).
