Control elements and display
Item Designation Function
A Rotating/pressing knob: Start/stop the stirring function,
change the settings of stirring speed in working screen,
navigation, selecting and changing the settings in the menu.
B Rotating/pressing knob: Start/stop the heating function,
change the settings of the temperature in working screen.
C Menu button: Press it once: main menu is displayed,
Press it a second time: back to the working screen.
D Back button: Return to the previous menu level.
E Timer button: Enable timer display.
F Weighing button: Enable weight display.
G Key button: Disable/enable button and rotating/pressing knob.
H F1 button: not currently assigned
I F2 button: not currently assigned
A
B
C
D
G
E
F
H
I
Fig. 10
