Advance Adapters 716808A - Manual

SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 716808A
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 4
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-25-14
1. 1 716811 STEERING COLUMN BUSHING
2. 2 716812 CLAMP (FOR NEW TIE ROD)
3. 1 716814 CLAMP
4. 1 716817 PITMAN ARM-POWER
5. 1 716821 NEW TIE RODEND FOR NEW TIE ROD
6. 1 716822 MOUNTING PLATE FOR COLUMN TO FLOORBOARD
7. 1 716831 SPECIAL TIE ROD WITH METRIC TOYOTA THREAD
8. 1 716833 NEW COLUMN BEARING ASSEMBLY (VEHICLES '73 & NEWER)
9. 1 716839 Kit STEERING BOX MOUNTING PLATE w/ Passenger side frame enclosure
10. 1 716863 STEERING SHAFT-36" COLLAPSIBLE W/O U-JOINT
11. 4 720064 8mm x 1.25 x 30mm H.H.C.S. (Column bearing bolts)
12. 4 720065 8mm x 1.25 HEX NUT (Column bearing nuts)
13. 4 723103 LOCK WASHER (Column bearing)
14. 4 723735 FLAT WASHER (Column bearing)
15. 1 723703 NYLON LOCK NUT 3/8"-16
16. 1 723725 H.H.C.S 3/8"-16 x 2"
**Kit does not include the Saginaw Steering Box or Steering Hoses.
This kit does not include the steering spud shaft or the column yoke. These items may be different when installing
a custom steering column and or using one of the steering boxes we sell or a box from a salvage yard. These items
should be ordered separately.
POWER STEERING CONVERSION
TOYOTA LAND CRUISER
Advance Adapters has been manufacturing steering conversion parts for installation of the Saginaw steering boxes into Toyota
vehicles for more than twelve years. The parts we furnish are of the highest quality available and we utilize only proven design
components for our kits. Before you consider the conversion, we recommend that you thoroughly read and understand the
complete procedure (located in the Land Cruiser Manual).
Do not take short cuts on steering installations. We
recommend that these conversions be installed by a qualified technician. All universal joints must be safety wired for double
protection.
Do not overlook any details. Remember that the control of your vehicle depends on the steering gear
performance. Failure of your steering system can result in severe damage and possible injury.
P/N 716834-30
- Spud shaft .730” dia. x 30T (manual & power) (male side is 1" double D as of 5/24/13)
P/N 716834-36
- Spud shaft .730” dia. x 36T (manual)(male side 1" double D as of 5/24/13)
P/N 716835
- Spud shaft .800” Dia. x 36T (power)(male side 1" double D as of 4/25/14)
P/N 716843
- Universal Joint 1” DD X 7/8”
P/N 716848
- Universal Joint 3/4” DD X .1”-48 GM
P/N 716849
- Universal Joint 3/4” DD X 1”DD
P/N 716851
- Land Cruiser column shaft 3/4” x 3/4” DD
Kit is Minus column Yoke, Steering box Spud Shaft &
U-Joint for the spud shaft.
