ADVANCE ADAPTERS INC. P/N: 716855
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 1
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 10-20-2008
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
1. 1 716855-BLK YJ STEERING BOX MOUNTING PLATE
2. 4 724303 7/16" LOCK WASHERS
3. 1 724343 7/16-14 x 2 GRD 8
4. 3 724359 7/6-14 X 2-1/2 GRD 8
5. 2 724301 7/16 LOCK NUT
6. 2 724302 FLAT WASHER
YJ STEERING BOX RELOCATION
Remove the small clamp that retains the power steering hose to the frame. Disconnect the steering shaft from the spline
at the end of the steering gear box. Remove the steering box from the frame.
Remove the original mounting plate. You will need to reuse the 4 bolts that held the stock mounting box plate to the
frame. The two lower bolts had sleeves that will also need to be retained, however these sleeves will need to be
shortened 1/2". The new bolts and lock washers are supplied to remount the steering box to the new plate. The lock
nuts and flat washers supplied are to fit the long stock bolts and to secure the bracket to the frame. The upper long
bolt may hit the steering box, you can grind 1/4" off the end of the bolt. You should also check clearance on the bottom
edge of the grill for clearance on the high pressure hose. You may need to clearance the grill for this hose. Once these
areas have been checked and modified as needed, install the steering box and plate onto the Jeep. The bolts should
be torqued to 55 ft.lbs.
