ADVANCE ADAPTERS INC.
P/N: 715534
P.O. Box 247, 4320 Aerotech Center Way
New Item: (6/99)
Paso Robles, CA 93447
PAGE 1 OF 1
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
01-21-09
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No.
Qty
Part No.
Description
1.
1
715534-1
GM MECH. CLUTCH SUPPORT BRACKET
2.
1
715534-2
GM MECH. CLUTCH PIVOT BRACKET
3.
1
723701
NUT 3/8"-16 PLATED
4.
1
723704
3/8" LOCKWASHTER PLATED
5.
1
723721
H.H.C.S. 3/8"-16 x 1" PLT GRADE 5
7.
2
720015
SPACER WASHERS(some AA B/H require the these between the
bracket & B/H on the lower mounting hole)
GM MECHANICAL CLUTCH LINKAGE BRKT.
FOR USE ON 712577 & 712576 KITS
This bracket is designed to locate the GM clutch pivot ball on the Advance Adapter 712577 and 712576 bellhousings.
The pivot bracket bolts to the bellhousing. The support bracket bolts to the pivot bracket, which then is bolted to
the transmission. Some linkages may need to be modified to fit properly.
