ADVANCE ADAPTERS INC. P/N: 713120
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 10-26-01
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
1. 1 713120L LEFT MOUNT
2. 2 713120F FRAME MOUNTS
3. 2 713120M ENGINE MOUNTING BRACKETS (Jeep #52019201AB)
4. 1 713120R RIGHT MOUNT
5. 2 720011 10mm x 1.5" NUT
6. 2 720038 10mm LOCKWASHERS
7. 2 723701 3/8" HEX NUTS
8. 8 723704 3/8" LOCK WASHERS
9. 8 723721 3/8"-16 x 1 LG. H.H.C.S. (Grade5)
10. 10 723735 3/8" FLAT WASHERS
11. 2 725001 1/2"-13 x 4.5" GRD. 5 BOLT
12. 2 725002 1/2" LOCK WASHERS
13. 4 725003 1/2" FLAT WASHERS
14. 2 725004 1/2" NUTS
JEEP 304, 360 & 401
MOTOR MOUNT ASSEMBLY
NOTES:
The frame brackets are designed to be welded into the Jeep frame rails. The rubber mounts bolt on top of the frame brackets.
Slots are provided in the frame brackets to allow for different frame widths. You can also rotate the rubber support on the
frame brackets to allow for narrow frame rails. If this is done, you may need to trim the outer edge of the frame bracket
so it does not interfere with the engine block.
These mounts fit all Jeep CJ5s, CJ7s and YJ Wranglers. The "L" brackets are a universal weld in style. To set the block
into the frame rails, we recommend that you assemble the mounts to the block with the rubber support & frame bracket
assembly. Bolt the block to the AMC transmission. Make sure the block is in a level position. Mark your frame where
the frame brackets are located. Weld the mounts and secure all bolts.
The following AMC blocks all have the same bolt pattern: 258 6-cyl., 4.2L, 4.0L, 304 V8, 360 V8 and 401 V8. NOTE:
On automatic transmissions, the only difference with these blocks is that the flexplates are balanced differently. Make sure
you match the flexplate with you block.
CAUTION:
These mounts are designed to mount different AMC V8 blocks into the various Jeep frame rails. Modifications to the
drivetrain may be necessary on some applications. For example: Automatic transmissions may have shift linkage problems
and fill tube interference. Manual transmissions sometimes have clutch linkage problems. BEFORE beginning your
installation, consider what areas may be effected.
