Advance Adapters 713119 - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 713119
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 1
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 10-27-98
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
INSTALLATION INSTRUCTIONS
These engine mounts are designed to bolt over the original S10 2.8 V6 engine rubbers. When used with the TH350
transmission or the original T4/T5 manual transmission, driveshaft modifications will not be required. The engine
mounts work best by first installing the welded mounts over the V6 rubbers. Install the special 7/16" hex head bolt
through the rubber and into the Advance Adapter support. Once the mounts are in position, the engine can then be
positioned into the chassis for final assembly.
1. 1 713119-L DRIVER'S SIDE ENGINE MOUNT
2. 1 713119-R PASSENGER SIDE ENGINE MOUNT
3. 1 714200 BOLT PACK
4. 1 GM001 GM INSTRUCTION MANUAL
CHEVY V6 4.3 ENGINE TO S10-S15 2WD
