ADVANCE ADAPTERS INC. P/N: 920013
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 11-26-12
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
KIT CONSISTS OF:
No. Qty. Part No. Description
SATURN OVERDRIVE SHIFT LINKAGE
T14 SATURN SHIFT KIT
1. 1 715651 CLIP
2. 1 716140 BRAKE YOKE 3/8" WITH PIN
3. 5 722546 SHIFTER BOOT SCREWS
4. 2 723105 H.H.C.S. 5/16"-18 x 1" LG
5. 1 920016 SHIFTER KNOB (SATURN)
6. 1 920017 WASHER
7. 1 920018 SHIFTER SNAP RING
8. 1 920019 SHIFTER HANDLE
9. 1 920021 SHIFTER BOOT DUAL HANDLE
10. 1 920022 SHIFTER BOOT RING DUAL HANDLE
11. 1 920032 T90 SINGLE LEVER SHIFT ROD
12. 1 920033 T14 SHIFT BRACKET
13. 1 920039 1/4"-20 x 1 H.H.C.S.
14. 1 920040 1/4"-28 JAM NUT
15. 1 920041 HEIM JOINT 1/4"-28
16. 1 722514 1/4"-20 LOCKNUT
17. 1 303081 IGUS BUSHING (PRESSED INTO THE HANDLE)
The shifter bracket fits directly over the top cover plate of the 3 speed transmission and the pivot extends outward
towards the passenger side of the vehicle. To access the assembly of the T14 transmission , the sheet metal tunnel
cover will need to be removed. When mounting the shifter bracket, you will need to use the steel spacer washers
between the top cover and the shifter bracket. New bolts have been supplied for the bracket assembly to the
transmission. The linkage rod must be installed into the slotted shift rail on the back side of the overdrive. The
rod must be slipped over the transfer case and certain installations may require modifications to the shifter rod.
With the extension rod in position and the shifter bracket in position, you can now install the handle assembly. The
handle will slip over the shifter bracket pin as illustrated. The clevis assembly (or brake yoke), will then slip onto
the shifter handle. At this point, the adjustment between the shifter handle and the linkage rod can be determined.
The handle should be positioned in a vertical position and the shifter rod in the overdrive should be positioned into
the neutral location.
