Advance Adapters 27-0044T - Manual

SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the
components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion,
we strongly recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter
components. We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment.
These manuals are normally available at automotive dealerships and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 27-0044T
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 1
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 10-30-02
BRONCO DANA 20/ 29 SPLINE NV4500 TRANS.
1. 1 383735 *CHEVY 11" DISC.
2. 1 Kit 50-0230 4WD 29 SPLINE NV4500 TO BRONCO DANA 20 T/C
3. 1 Kit 712551 DODGE NV4500 TO FORD V8 BHSG.
4. 1 Kit 716050D1 NV4500 SHIFT HANDLE ASSY.
5. 1 Kit 716101-2 NV4500 MOUNTING PLT. KIT BRONCO
INSTALLATION NOTES:
This kit is designed to fit the Dodge Standard Duty NV4500 transmission.
This kit requires the use of a stock Ford bellhousing with a 4.848" index diameter.
This is a parts pull sheet. Refer to the instruction sheet on each kit for proper installation.
