Advance Adapters 27-0011T - Manual

SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the
components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion,
we strongly recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter
components. We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment.
These manuals are normally available at automotive dealerships and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 27-0011T
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 1
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 11-30-10
CHEVY V8 TRANNY KIT
NV4500 to NP231 TRANSFER CASE
1. 1 Kit 50-0204 NV4500 TO NP231 WRANGLER 23T KIT
2. 1 Kit 50-0231 29 SPLINE NP231 INPUT GEAR
3. 1 Kit 712576 NV4500-1996 GM BHSG ADAPT. KIT
4. 1 Kit 716008 WRANGLER CROSSMEMBER MOUNT
5. 1 Kit 716050D1 NV4500 SHIFT HANDLE ASSY
6. 1 716130 HYD. MASTER CYL. FITTING
7. 1 716130H 42" STAINLESS HOSE-3 FITTING
8. 1 Kit 716331 *JEEP SLAVE CYL. KIT
9. 1 716130F SLAVE CYLINDER FITTING
INSTALLATION NOTES:
This kit is designed to fit the 29 spline Dodge Standard Duty NV4500 transmission.
This kit must also have a new input shaft 52-0221 or you should be using our transmission P/N 26-0029GM
If you have a 1997-2000 TJ, you will be required to purchase P/N 716130TJ (Hydraulic master cylinder fitting).
This is a parts pull sheet. Refer to the instruction sheet on each kit for proper installation.
