KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-9810
P.O. Box 247, 4320 Aerotech Center Way New Item: (06/95)
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-20-01
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
1. 1 51-9807 CASTING (3.500" Long)
2. 1 52-9810 DANA 300 INPUT SPUD SHAFT W/10T INTERNAL
3. 1 716308 NEW BEARING FOR DANA 300 BRG. RETAINER
4. 1 716515 GASKET
5. 1 716517 GASKET
6. 1 716749 NATIONAL SEAL (#471870)
7. 1 723701 3/8"-16 HEX HEAD NUT
8. 14 723704 3/8" LOCK WASHER PLT.
9. 1 723711 STUD BOLT 3/8"-16 x 2"
10. 12 723723 H.H.C.S. 3/8"-16 x 1-1/2"
11. 1 723740 S.H.C.S. 3/8"-16 x 1-1/2"
12. 1 JP001 JEEP INSTRUCTION MANUAL
GM TRUCK 4WD 4SP MODEL SM465 10 SPLINE
JEEP DANA 300 T/C (Short Design)
PLEASE NOTE THE FOLLOWING:
The new transmission support area can be used with your original transmission support with only minor modifications.
A spacer plate, P/N 716017, could be used to adapt your original mount to the bottom of the new adapter.
Note: Part
No. 716021 crossmember mount should not be used with this adapter.
This adapter kit has an overall assembled length of 15-1/2". This length will be very compatible when replacing the
T4, T5 or SR4 transmissions. If using this transmission with the Jeep 6 cylinder, you will need to use Advance Adapters
bellhousing No. 712571. This adapter could be used with V8 conversions and will require driveshaft modifications.
Adapter Kit No. 50-9800 uses the same transmission, but the adapter is 3-1/2" longer providing a better V8 engine
location and leaving the transfer case near its original location.
