Advance Adapters 50-9808 User Manual

Kit consists of

background image

KIT CONSISTS OF:

No.

Qty

Part No.

Description

ADVANCE ADAPTERS INC.

P/N: 50-9808

P.O. Box 247, 4320 Aerotech Center Way

New Item: (08/94)

Paso Robles, CA 93447

PAGE 1 OF 3

Telephone: (800) 350-2223

Fax: (805) 238-4201

Page Rev. Date:

01-15-08

SPECIAL NOTE:

The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will

void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend

that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a

service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive

dealerships and parts stores.

1.

1

51-9808

CASTING 5.250" LONG

2.

1

52-9700

SPUD SHAFT - SM465/JEEP NP T/C LONG 23 SPL. (Ref: 711397)

3.

1

716515

GASKET

4.

1

716517

GASKET

5.

1

716729

NATIONAL SEAL

6.

1

723701

3/8"-16 HEX NUTS

7.

14

723704

3/8" LOCK WASHER PLT.

8.

1

723711

STUD BOLT 3/8"-16 x 2"

9.

12

723723

H.H.C.S. 3/8"-16 x 1-1/2"

10.

1

723740

S.H.C.S. 3/8"-16 x 1-1/2"

11.

1

JP001

JEEP INSTRUCTION MANUAL

GM TRUCK 4WD 4SP MODEL SM465 10 SPLINE

JEEP NP231 TRANSFER CASE 23T (Short Design)

PLEASE NOTE THE FOLLOWING:

This adapter kit has an overall length of 17-1/4". The length will be very compatible when replacing the AX15 5 speed

transmission. When using this transmission with the Jeep 6 cylinder, you will need to use the Advance Adapters bellhousing

No. 712571. This adapter could be used with both V8 and Straight 6 engine conversions and will offer the maximum

driveshaft length capable in the Wrangler conversion.

DO NOT USE THIS KIT FOR REPLACEMENT OF THE

PEUGEOT 5 SPEED unless you purchase #716053 23T input gear replacement for the 21T transfer case.

This kit fits both New Process transfer cases with either a long or short T/C input stickout. If your vehicle

was equipped with a long T/C input stickout (replacing a 999/904 transmission) an additional spacer adapter

plate is necessary part number AS-8610. This plate will eliminate a chance of assembly pre-load. Please call

for pricing on this plate, when replacing the Jeep automatics.
