Advance Adapters 50-9702 - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-9702
P.O. Box 247, 4320 Aerotech Center Way New Item: (3/93)
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 05-29-01
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
1. 1 51-9702 CASTING 5-1/4" LG. (Jeep-Dana 300)
2. 1 52-9700 SPUD SHAFT 23 SPLINE
3. 1 716453 SNAP RING
4. 1 716454 SET COLLAR
5. 1 716508 GASKET
6. 1 716517 GASKET (Dana 300)
7. 9 723701 3/8"-16 NUTS
8. 14 723704 3/8" LOCKWASHER PLT.
9. 1 723710 3/8"-16 X 2.5" STUD.
10. 8 723711 3/8"-16 X 2" STUD.
11. 5 723722 3/8"-16 X 1.25" H.H.C.S.
12. 1 JP001 JEEP INSTRUCTION MANUAL
GM TRUCK 4SP MODEL SM420 TO
JEEP DANA 300 TRANSFER CASE
INSTALLATION NOTE:
This adapter kit replaces Kit No. 50-9700 that utilized a two piece adapter housing that had an overall length
of 5-7/8". This new adapter kit was re-designed in March 1993, to use a 5-1/4" one-piece adapter housing.
Note: If using our 716021 crossmember mount with this adapter, you will need to grind some
clearance on the crossmember block for installation.
