Advance Adapters 50-8901 - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-8901
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711089-10
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-02-10
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that
a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at
automotive dealerships and parts stores.
OPTIONAL ITEMS:
Qty Part No. Description
1. 1 51-7300 CASTING (Ref: 711173)
2. 1 51-8500 ADAPTER HOUSING (Ref: 711185)
3. 1 52-1500 SHAFT (Ref: 711315)
4. 1 52-8900 700R-4 OUTPUT SHAFT (Ref: 711389)
5. 1 Pack 714203 BOLT PACK (50-7300)
6. 1 716082 700R PLASTIC WASHER
7. 1 716301 BEARING
8. 1 716507 T/C GASKET
9. 2 716511 "O"-RING
10. 4 720015 FLAT WASHER
11. 4 720047 H.H.C.S. 10mm X 1.5 X 70mm LG.
12. 1 728701 NUT
13. 1 728702 7/8" FLAT WASHER
14. 1 TLC001 LAND CRUISER INSTRUCTION MANUAL
GM 700R-4 AUTOMATIC OVERDRIVE
TO LAND CRUISERS 1963-73 (3 SPEED)
1 716004 CROSSMEMBER ASSY
(Includes #716003
Mount)
NOTE: This kit requires the 2WD output shaft to
be shortened. If you are using this kit on a newer
hex bolt pattern 4L60E transmission, then you
will be required to use our 51-0405 adapter
housing. Please note that the cut off location on
the output shaft must be made after this adapter
is installed on the transmission. This 51-0405
adapter make the hex pattern 4L60E transmission
look just like the square bolt pattern transmission,
and the cut off location for the output shaft is
shown on this instruction sheet is for the square
bolt pattern transmission.
