ADVANCE ADAPTERS INC. P/N: 50-8800
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711088
Paso Robles, CA 93447 PAGE 1 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 10-03-96
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
KIT CONSISTS OF:
No.
Qty Part No. Description
TOYOTA L/C 4 SPEED TRANSMISSION TO
TOYOTA LAND CRUISER 3 SPEED T/C
INSTALLATION INSTRUCTIONS:
This adapter kit is provided for use with the Toyota Land Cruiser 4 speed transmissions that are going to be used with
the early model 3 speed transfer cases. The output shaft is identical to the Toyota Land Cruiser shaft except the splines
on the end of the shaft are 1-3/8"-10. The original 4 speed shaft has 16 splines and is not interchangeable with the earlier
model transfer cases.
With the shaft installed into the transmission, you must then install the new bushing over the shaft. This bushing will
provide the proper location for assuring gear alignment. The two transfer case gears will then slip directly onto the new
output shaft. The original rear output bearing from the 3 speed transfer case will then be installed along with the washer
and nut on the end of the shaft. Maximum torque should be 75 ft/lbs.
This transmission adapter is not compatible with the original Toyota P.T.O. gear boxes or the Fairy overdrive
transmissions.
1. 1 52-8800 MAIN SHAFT (Ref: 711388)
2. 1 716160 SPACER BUSHING
3. 1 716507 GASKET
4. 1 728701 7/8" LOCK NUT
5. 1 728702 7/8" FLAT WASHER
