Advance Adapters 50-7503 User Manual
Kit consists of
ADVANCE ADAPTERS INC.
P/N: 50-7503
P.O. Box 247, 4320 Aerotech Center Way
Old Part No: 711075-T98
Paso Robles, CA 93447
PAGE 1 OF 3
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
12-11-00
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
KIT CONSISTS OF:
No.
Qty
Part No.
Description
FORD T98 4-SPEED TRANSMISSION TO
JEEP DANA 300 TRANSFER CASE
1.
1
51-7502
ADAPTER CASTING
2.
1
52-7502
T98 MAIN SHAFT
3.
1
716452
SNAP RING (Jeep #8132631)
4.
1
716517
GASKET (Dana 300)
5.
1
716722
SEAL (National #472319)
6.
2
723723
H.H.C.S. 3/8"-16 x 1-1/2"
7.
2
723728
S.H.C.S. 3/8"-16 x 2-1/2"
8.
2
723735
FLAT WASHER 3/8" STD.
9.
2
724328
H.H.C.S. 7/16"-14 x 1-1/4"
10.
1
JP001
JEEP INSTRUCTION MANUAL
Before assembly of the transmission with the new
main shaft, you must verify that the correct shaft
is being used. Your spline count on the shaft must
be 23-splines. We also manufacture a 27-spline
shaft that will not be compatible with your Dana
300 transfer case.
