KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-6402
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711064-23
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 08-21-08
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
GM TH400 AUTOMATIC TO JEEP
NEW PROCESS - 23 SPLINE T/C
1. 1 51-6401 ADAPTER HOUSING (Ref: 711164-SS)
2. 1 52-6401 TH400 OUTPUT SHAFT (23-SPL) (Ref: 711364-23)
3. 1 716165 SOFT PLUG
4. 1 716510 GASKET (GM #8624709)
5. 1 716517 GASKET
6. 1 716729 SEAL (NAT #456057)
7. 6 302071 3/8"-24 HEX NUTS
8. 6 723740 3/8"-16 x 1-1/2" S.H.C.S.
9. 1 JP001 JEEP INSTRUCTION MANUAL
GM TURBO 400 3 SPEED AUTOMATIC
The GM TH400 has a case length of 24-3/4", 13 bolts for holding the oil pan in position and is available in 3 different engine
to transmission bolt patterns. Make sure you have selected the proper TH400 for your particular engine. The AMC TH400
case when used with the Chevy engine will require adapter Kit No. 716133. The rear side of the transmission case will
have a hex shaped bolt pattern that uses 6 bolts. There are several various lengths of output shafts that these transmissions
have been equipped with, but all of our new output shafts will be interchangeable with your transmission. The new shaft
supplied with your kit should be installed by a competent mechanic. The speedometer gear is normally located in the
