Advance Adapters 50-6306A - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-6306A
P.O. Box 247, 4320 Aerotech Center Way Old Part No:
Paso Robles, CA 93447 PAGE 1 OF 5
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-10-13
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
OPTIONAL ITEMS:
Qty Part No. Description
1. 1 51-6300 CASTING (Assembled by AA)
2. 1 52-6302 SPUD SHAFT (Assembled by AA)
3. 1 Pack 714201 BOLT PACK (50-6300)
4. 1 716308 BEARING (#6209) (Assembled by AA)
5. 1 716450 SNAP RING (Assembled by AA)
6. 1 716456 SNAP RING (Assembled by AA)
7. 1 716511 "O" RING
8. 1 716517 GASKET
9. 6 723711 STUD BOLT 3/8"-16 X 2" LG.
10. 1 716738 NATIONAL SEAL (#473459) DUAL LIP
11. 1 716095B 23T NP231 T/C INPUT GEAR
12. 1 716325A NEEDLE BEARING NP231 GEAR
1 716008 CROSSMBR .
MOUNT
1 715523 T/C SHIFTER
BRKT.
GM 4WD TH350 AUTOMATIC TO JEEP NP231 T/C
21 SPL. upgrading to a 95 and newer 23 SPL.
