Advance Adapters 50-4903 - Manual

SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that
a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at
automotive dealerships and parts stores.
ADVANCE ADAPTERS INC. P/N: 50-4903
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711049-19
Paso Robles, CA 93447 PAGE 1 OF 4
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-24-12
KIT CONSISTS OF:
No. Qty Part No. Description
GM 2WD TRUCK 4 SP MODEL SM465 TO
TOYOTA LAND CRUISER 1980-89 (19SPL)
1. 1 51-0800 ADAPTER PLATE (Ref: 711108)
2. 1 51-8700 ADAPTER CASTING (Ref: 711187)
3. 1 52-4902 SPUD SHAFT W/19 TOOTH (Ref: 711349-19)
4. 1 716013 TOYOTA RETAINER
5. 1 716142 BUSHING/GEAR LOCATOR
6. 1 716301 BEARING
7. 1 716457 SET COLLAR
8. 1 716515 GASKET
9. 1 716568 GASKET
10. 2 723701 NUT 3/8"-16 PLATED
11. 8 723704 3/8" LOCK WASHER
12. 2 723711 STUD BOLT 3/8"-16 x 2" LG. (Install 1/2" ONLY into transmission case)
13. 6 723723 H.H.C.S. 3/8"-16 x 1-1/2"
14. 8 724302 7/16" FLAT WASHER
15. 2 724309 7/16" H.H.C.S.
16. 3 724311 7/16" H.H.C.S.
17. 2 724328 7/16"-14 x 1-1/2" GR 5
18. 3 724345 HEX HEAD BOLT 7/16"-14 x 5"
19. 2 724349 H.H.C.S. 7/16"-14 x 1-1/2"
20. 1 TLC001 LAND CRUISER INSTRUCTION MANUAL
If your transfer case was coupled to a manual transmission, Toyota used a single lip seal in the front of the transfer case.
We recommend changing the seal with a double lip seal that was used on the stock automatic applications.
Toyota # 90316-48003
