SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We
recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally
available at automotive dealerships and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-4303
P.O. Box 247, 4320 Aerotech Center Way New Item: (01/02)
Paso Robles, CA 93447 PAGE 1 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 09-29-14
1. 1 51-9920 SPECIAL DANA 20 ADAPTER PLATE
2. 1 52-4303 SPECIAL SPUD SHAFT 31T INTERNAL
3. 1 715544 SHIFTER LINKAGE BRACKET
4. 1 715544B TRANSFER CASE PIVOT BOLT
5. 1 716223 BEARING RETAINER
6. 1 716302 SEALED BEARING
7. 1 716455 SNAP RING
8. 1 716513 GASKET
9. 1 716517 GASKET
10. 1 716714 "O" RING
11. 6 723704 3/8" LOCK WASHERS
12. 4 723722 3/8"-16 x 1-1/4" LONG H.H.C.S.
13. 2 723723 3/8"-16 x 1-1/2" LONG H.H.C.S (SHIFTER BRKT BOLTS)
14. 6 723729 3/8"-16 x 1-3/4" LONG S.H.C.S.
15. 1 726207 PIVOT BOLT FLAT WASHER
ZF TRANSMISSION
TO BRONCO DANA 20
INSTRUCTIONS:
This kit is supplied with a new spud shaft, and sealed bearing. These components will need to be installed into our alignment
retainer along with the stock Bronco Dana drive gear. Make sure all snap rings are in place. Install the O-ring on the retainer
along with a small amount R.T.V. Blue silicone, and then install the retainer to your transfer case. Bolt the adapter ring
to the Dana 20 using the (6) S.H.C.S. bolts. Rotate the spud shaft to check for proper installation.
The new casting bolts to the Dana 20 and could be rotated in several options since the bolt pattern is symmetrical, however;
the ZF pattern is not so the casting must be orientated correctly to the Dana 20 in order to bolt correctly to the ZF
transmission. We have put a small drill mark on the casting surface to indicate the top of the casting and this should be
bolted to the transfer case with this mark closest to the floorboard of the vehicle.
When assembling the transmission to the transfer case, DO NOT FORCE the two gear boxes together. If the shaft is
too long, there is the possibility of pre-loading the transmission bearings, causing premature failure. Take extra time to
make sure that the shafts do not bottom out internally. If there is any interference problem, it may be necessary to grind
the end of the new output shaft to obtain the proper length.
A shifter bracket has been provided for a "T" style T/C shifter handle. The stock tailhousing of the ZF transmission must
be modified to fit our bracket. Our bracket will require some of the aluminum webbing to be ground off on the left side
to fit the bracket; and it may also require some additional grinding to fit the "T" handle linkage. Before installing your
transmission and transfer case assembly into your vehicle, modify the tailhousing to fit of this linkage and bracket. The
transfer case shifter handle and the ZF shifter handle may be too close together on some applications. The ZF handle may
require a small bend to clear the transfer case shifter handle.
NOTE NOTE NOTE NOTE NOTE :::::
This adapter will only work with the "T"
style shifter. If your vehicle has a "J"
style, it will need to be replaced
This kit can be used on a C6 4WD
transmission. You will need to purchase
a seal for the retainer P/N 716755.
