Advance Adapters 50-3103 - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-3103
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 03-20-01
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
OPTIONAL ITEMS:
Qty Part No. Description
1. 1 51-1700 CASTING (Ref: 711117)
2. 1 52-1301 SPUD SHAFT (Ref: 711313-23)
3. 1 716308 BEARING
4. 1 716450 SNAP RING
5. 1 716456 SNAP RING (T/A N5000-334)
6. 1 716511 "O"-RING
7. 1 716568 GASKET
8. 2 716700 SEAL
9. 4 723728 3/8"-16 X 2-1/4" S.H.C. S.
10. 1 724319 7/16"-20 X 3/8" SET SCREW
11. 1 728701 7/8" NYLOCK NUT
12. 1 JP001 JEEP INSTRUCTION MANUAL
1 716003 CROSSMEMBER MT
1 716302 SEALED BEARING
1 716001 T86 BRG. RET
1 716010 MODULATOR
GM TH350 TO SCOUT DANA 20 & 300
1974-80 REPLACING I.H. 727 AUTOMATIC
