KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-3001
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711030-LS
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-24-09
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
OPTIONAL ITEMS:
No. Part No. Description
1. 1 51-1700 CASTING (Ref: 711117)
2. 1 52-1300 SPUD SHAFT (Ref: 711313)
3. 1 716308 BEARING
4. 1 716450 SNAP RING
5. 1 716456 SNAP RING (T/A N5000-334)
6. 1 716511 "O"-RING
7. 1 716568 GASKET
8. 2 716700 SEAL
9. 4 723728 3/8"-16 x 2-1/4" S.H.C.S.
10. 1 724319 7/16"-20 x 3/8" SET SCREW
11. 1 728701 7/8" NYLOCK NUT
12. 1 JP001 JEEP INSTRUCTION MANUAL
1 716003 CROSSMEMBER MT
1 716302 SEALED BEARING
1 716001 or
716002
T86/T90 BRG. RET
1 716009 SMALL YOKE KIT
1 716010 MODULATOR
GM TH350 AUTOMATIC
JEEP & SCOUT DANA 18/20 1945-79
Front Yoke Clearance
Jeeps 1965 and earlier with the Dana 18 transfer case used a large
diameter yoke. When installing these transfer cases up to the GM
TH350 transmission, you will run into a yoke clearance issue on the
transmission pan. We offer a smaller yoke kit for the early version
Dana 18 for this clearance problem. This kit is,
P/N 716009 which
includes the new transfer case yoke bearing cross and stub yoke.
Our new yoke on the
left and the stock yoke
on the right.
