KIT CONSISTS OF:
No.

Qty.

Part No.

Description

SPECIAL NOTE:

The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will

void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.

ADVANCE ADAPTERS INC.

P/N: 50-2801

P.O. Box 247, 4320 Aerotech Center Way

Old Part No: 711028-16

Paso Robles, CA 93447

PAGE 1 OF 2

Telephone: (800) 350-2223

Fax: (805) 238-4201

Page Rev. Date:

12-14-07

NOTE: If your new shaft varies from the original shaft, you may have

a Ford Top Loader overdrive transmission adapter plate.

1.

1

51-1500

ADAPTER PLATE (Ref: 711115)

2.

1

52-2801

MAIN SHAFT (Ref: 711328-16)

3.

1

716502

GASKET

4.

1

716507

GASKET

5.

5

724317

S.H.C.S. 7/16"-14 x 1-1/4" LG.

6.

3

720089

12mm x 1.25 x 130mm

7.

2

720063

12mm x 1.25 x 90mm

8.

1

728701

NYLON LOCK NUT

9.

1

728702

WASHER

10.

1

TLC001

LAND CRUISER INSTRUCTION MANUAL

FORD T&C 10 BOLT TOP LOADER 4 SPEED

TOYOTA L/C 4 SPEED TRANSFER CASE

This kit is designed for a top shifted
transmission. If used on a side
shifted transmission, shift linkage
must be fabricated
