Advance Adapters 50-2000 - Manual

KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-2000
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711020
Paso Robles, CA 93447 PAGE 1 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 09-20-96
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
OPTIONAL ITEMS:
Qty Part No. Description
1. 1 51-1000 ADAPTER PLATE (Ref: 711110A)
2. 1 52-2000 MAIN SHAFT (Ref: 711320)
3. 1 716033 BUSHING
4. 1 716502 GASKET
5. 1 716568 GASKET
6. 1 723750 SEAL WASHER
7. 3 724317 7/16"-14 X 1-1/4" S.H.C.S.
8. 2 724320 7/16"-14 X 1-1/4" SPECIAL S.H.C.S.
9. 1 728701 NYLON LOCK NUT
10. 1 JP001 JEEP INSTRUCTION MANUAL
FORD T & C 4 SPEED TO
JEEP & SCOUT DANA 18/20
1 715506 BRACKET
1 715631 ROD KIT
1 716001 or 716002 T86-T90
BRG. RETAINER
1 716302 SEALED BRG
1 716003 MOUNT
