KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-1300
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711013
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 02-27-03
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the
components will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete
your conversion, we strongly recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly
of Advance Adapter components. We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams
and other related equipment. These manuals are normally available at automotive dealerships and parts stores.
OPTIONAL ITEMS:
Qty Part No. Description
1. 1 51-0600 ADAPTER CASTING (Ref: 711106)
2. 1 52-1300 SPUD SHAFT (6-Splines)(Ref: 711313)
3. 1 52-3200 OUTPUT SHAFT (Ref: 711332)
4. 1 716308 BEARING (#6209)
5. 1 716450 SNAP RING (GM #378-5205)
6. 1 716510 GASKET (GM #862-4709)
7. 1 716568 GASKET
8. 1 716707 SEAL (NAT. #472144)
9. 6 723701 HEX NUT
10. 11 723704 3/8" LOCKWASHER
11. 6 723711 3/8"-16 x 2" STUD BOLTS
12. 5 723723 3/8"-16 x 1-1/2" H.H.C.S. (T/C BOLTS)
13. 1 728701 NYLON LOCK NUT
14. 1 JP001 JEEP INSTRUCTION MANUAL
1 716003 CROSSMEMBER
1 716302 SEALED BEARING
1 716001 (T86) LARGE HOLE OR
1 716002 (T90) SMALL HOLE
BRG. RETAINER
NOTE: Two TH400 bolt patterns have been drilled
into this housing; one is for a GM TH400 and the
other is rotated for the AMC TH400.
TURBO 400 TO JEEP & SCOUT VEHICLES
DANA 18/20 TRANSFER CASE
