Advance Adapters 50-1114 User Manual
Nissan titan to atlas t/c adapter plate

KIT CONSISTS OF:
No.
Qty
Part No.
Description
ADVANCE ADAPTERS INC.
P/N: 50-1114
P.O. Box 247, 4320 Aerotech Center Way
New Item:
Paso Robles, CA 93447
PAGE 1 OF 2
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
04-27-06
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that
a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at
automotive dealerships and parts stores.
1.
1
51-1114
ADAPTER PLATE
2.
11
720037
10mm-1.5 x 35mm H.H.S.C.
3.
3
720088
10mm-1.25 x 40mm STUDS
4.
6
723704
3/8" LOCK WASHERS (ATLAS TO ADAPTER PLATE)
5.
6
723722
3/8"-16 x 1.25" H.H.C.S. (ATLAS TO ADAPTER PLATE)
NISSAN TITAN TO ATLAS T/C
ADAPTER PLATE
Studs in tailhsg. Nuts on atlas side
All others-
Bolt thru tailhsg. Thread into plate.
Dowel
Dowel
