Advance Adapters 50-0226 User Manual
Kit consists of
ADVANCE ADAPTERS INC.
P/N: 50-0226
P.O. Box 247, 4320 Aerotech Center Way
New Item: (09/97)
Paso Robles, CA 93447
PAGE 1 OF 3
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
12-18-09
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We
recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally
available at automotive dealerships and parts stores.
KIT CONSISTS OF:
No.
Qty
Part No.
Description
1.
1
51-0224
ADAPTER CASTING
2.
1
52-0226
16 SPLINE SPUD SHAFT (23T INTERNAL)
3.
1 Kit
715532
TRANSFER CASE LINKAGE BRKT. ASSY.
4.
1
716199
RETAINER
5.
1
716301
SEALED BEARING
6.
1
716507
GASKET
7.
8
720046
10mm-1.5 x 40mm LONG
8.
2
723735
3/8" FLAT WASHER
9.
2
723739
3/8"-16 x 7/8" H.H.C.S.
10.
5
724303
7/16" LOCKWASHERS
11.
8
724324
7/16" HIGH COLLAR LOCK WASHER
12.
3
724345
7/16" x 14 x 5" HEX HEAD BOLT
13.
2
724349
7-16" x 14 x 1-1/2" H.H.C.S.
14.
1
728701
NYLON NUT
15.
1
728702
7/8" FLATWASHER
16.
1
TLC001
LAND CRUISER INSTRUCTION MANUAL
17.
1
NV001
NV INSTRUCTION MANUAL
NOTE:
This adapter kit has an overall transmission assembled length of 18.750". This kit will work
ONLY
with Dodge NV4500
gas transmissions having 23 spline output.
CAUTION:
There are two 3/8" holes located on the side of the adapter for the mechanical shifter linkage. If your vehicle
has a 3 speed vacuum type shifter, these holes are not going to be used. They will need to be plugged with the
hardware provided and small amount of silicone.
DODGE NV4500 5 SPEED23 SPLINE OUTPUT
TO TOYOTA L/C 16 SPLINE
