ADVANCE ADAPTERS INC. P/N: 712570
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 6
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 02-10-09
KIT CONSISTS OF:
No. Qty Part No. Description
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components.
We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are
normally available at automotive dealerships and parts stores.
1. 1 712570-BLK BELLHOUSING (Transmission index diameter 4.686")
2. 1 716156GM PILOT BUSHING W/ .590" I.D.
3. 1 716109 3/4" SOFT PLUG
4. 1 716176 CLUTCH RELEASE ARM
5. 1 716180 BALL PIVOT
6. 2 716330 SPECIAL BOLTS FOR FLYWHEEL SENSOR
7. 1 716332 CLUTCH ARM BOOT (see NOTE 1 below)
8. 2 723134 H.H.C.S. 5/16"-18 x 1-1/4" LG. (Slave Cylinder)
9. 6 724303 7/16" LOCK WASHERS
10. 4 724328 H.H.C.S. 7/16"-14 x 1-1/4" LG. (Transmission)
11. 1 JP001 JEEP INSTRUCTION MANUAL
NOTE 1: The throw out arm boot provided in this bellhousing kit was designed for a Jeep throw out arm. The
arm provided in this kit is a Chevrolet arm. The boot may need to be modified for the correct arm location in
the boot.
NOTE 2: The 4.0L blocks replacing a manual transmission used a 2 piece pilot bushing. Both pieces must be
removed, the bearing and the sleeve. If these pieces are not removed, the new brass pilot bushing will not
fit. We do not offer a smaller pilot bushing to fit the reducer sleeve. On 4.0L that were originally mated to
a automatic the new pilot bushing will fit without any modifications.
NOTE 3: When using this bellhousing with a SM420, you will be required to drill out the two lower holes in the
new bellhousing and use your existing bolts.
BELLHOUSING FOR JEEP 4.0 HIGH OUTPUT
6 CYLINDER ENG. TO GM SM420 TRUCK 4SP
