ADVANCE ADAPTERS INC. P/N: 712559
P.O. Box 247, 4320 Aerotech Center Way New Item: (02/97)
Paso Robles, CA 93447 PAGE 2 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 09-09-98
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
DODGE NV4500 5 SPEED (Gas) 4 CYLINDER
AMC JEEP ENG./AX4 BHSG. (EXT. Slave Cyl.)
8. The pilot bushing in the AMC engine crank must be replaced with the new bushing supplied.
9. The clutch disc for the original 4 cylinder installation used a 1"-14 spline size and the new transmission requires a
1-1/8"-10 spline. Centerforce clutch disc Part No. 383824 will be required for the new installation.
10. The input gear of the NP231 transfer case will need to be changed from 21 spline to 23 spline in order for the new
NV4500 to properly fit. Advance Adapter's can supply Part No. 716053 for the transfer case modification.
