JEEP T90 3 SPEED TRANSMISSION TO
CHEVY & BUICK ENGINES
ADVANCE ADAPTERS INC. P/N: 712502
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 3 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-13-13
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components.
We recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are
normally available at automotive dealerships and parts stores.
NOTES:
1.
Be sure to grease inside pocket diameter of bearing. This will provide
lubrication on the bearing retainer.
2 . Release bearing should have .060" clearance between fingers and face
of bearing.
3. Clutch disc should have .030" clearance between flywheel and disc
when fully disengaged.
4. Grease ball pivot for maximum clutch performance. (Fits all GM bell-
housings). The snap ring inside of clutch arm will hold lever on ball
pivot.
11" CLUTCH ITEMS:
11" CLUTCH PRESSURE PLATE (Part #CF165552)
11" CLUTCH DISC. (Part #383735)
CLUTCH RELEASING BEARING (Part No. N1430)
BALL PIVOT (Part #716180)
10.5" CLUTCH ITEMS:
10.5" CLUTCH PRESSURE PLATE. (Part #CF360056)
10.5" CLUTCH DISC. (Part #383271)
CLUTCH RELEASE BEARING (Part #N1430)
BALL PIVOT (Part #716180)
