Chapter 8 – Operation
54 TB80/TB85J – 0112477
Driving Lights
The optional driving lights are for use in dimly lit areas
and are not intended for driving on public roadways. There
are two headlights at the front of the chassis and two
blinking taillights at the rear of the chassis.
The lights are operational when the machine is set up for
operation from the upper controls and the light switch is
turned on (refer to Figure 8.11).
Figure 8.11 – Upper Controls
If the engine is running, the idle speed increases when
the driving lights are turned on.
Note
Working with the driving or platform work lights on, while
the engine is off, can discharge the batteries enough
that the engine will not start or the emergency power sys-
tem will not operate. If the engine cannot be left running
while the lights are on, start and run the engine for at
least 15 minutes each hour.
Platform Work Lights
The optional platform work lights are located on the top
rail of the platform next to the upper controls (refer to
Figure 8.12). The direction a light points can be adjusted
by using two
1 /
2
″ wrenches to loosen the clamp below the
light.
Figure 8.12 – Upper Controls
The lights are operational when the machine is set up for
operation from the upper controls.
Light Switch
