Page 48
Chapter 7 – Prestart Inspection
44
TB80/TB85J – 0112477
DANGER
DO NOT ALTER OR DISABLE
LIMIT SWITCHES, SAFETY
SWITCHES, OR INTERLOCKS.
451986
451986
0151410
Top View Of Chassis
0110708
451986
Rear
Front
Radiator – Ford and Cummins
0151410
CRUSHING HAZARD. Be certain area
under jack shoe plate is unobstructed
and can support rear axle weight.
0110708
DANGER
RETRACT
LOWER
EXTEND
AXLES
RAISE
0110708
Ford Engine – Left Side
0151410
