Technical data
Page 6 of 25
Safe working load (SWL)
equivalent to
Maximum platform height
Maximum working height
Platform length
Platform width
Platform guard rail height
Toe board height
Maximum allowable manual force
Maximum allowable wind speed
Maximum allowable chassis inclination
Electrical system
Motor
Batteries
Battery charger
Hydraulic system
Maximum pressure
Reservoir capacity
Function speeds (approx.)
Raise
Lower
Approx. no. of lifts (fully charged with SWL)
Overall length
Overall height (stowed)
Overall width (with stabilisers deployed)
Overall width (without stabilisers)
Overall mass (GVW) without stabilisers
Overall mass (GVW) with stabilisers
Weight (without stabilisers)
Section 2
SPECIFICATION
240kg
1 person + 160kg tools and materials
2.5 metres
4.5 metres
1.01 metres
0.52 metres
1.10 metres
0.15 metres
200 Newtons
0 metres/sec*
0 degrees
12 volt DC
0.7 kW
1 x 80 Ah
Universal 90V to 240V AC
13 MPa
1.22 litre
24 seconds
25 seconds
120
1.26 metres
1.72 metres
1.30 metres
0.70 metres
343kg
365kg
Maximum wheel load 350kg
Operator’s Safety and Maintenance Handbook (
343kg
* For use in indoor exposed areas up to 12.5m/sec wind speed – pack available on request
Pop-Up+ dual use machine rev.0.0.1.0210)
