Figure 8.15 - Platform Control Box Operation
Platform Moving Switch Illustration
■ Securing for Day
At the end of each work day the MHP15J should be
re turned to the STOWED POSITION and locked as
de
scribed un
der “Stowing” in the "Stowing and
Trans porting" chap ter 10.
MHP15J – 11995A
page 8 - 7
8. Operation
JIB
BOOM
3. Jib Boom
5. Platform Rotation
UP
UPPER
BOOM
2. Upper Boom
UP
DOWN
DOWN
SLEW
4. Slew
LEFT
RIGHT
ROTATE
PLATFORM
LEFT
RIGHT
1. Lower Boom
LOWER
UP
DOWN
BOOM
