4. Gauges
■ Hourmeter
Figure 4.1 - Hourmeter
The hour me ter is ba si cally an elec tric clock. It ac -
cu
mu lates time when the mas ter key switch is
turned on. The hour me ter can not be re set. An
MHP qual i fied ser vice tech ni cian can use it to tell
when it is time for the pe ri odic main te nance listed in
the main te nance man ual.
■ Level Bubble
Figure 4.2 - Level Bubble
A level bub ble is mounted on the trailer base.
Watch the bub ble while you set the sta bi lis ers.
Lower the sta bi lis ers, front ones first, one at a time
just enough to cen ter the bub ble in the cir cle on top
of the gauge. When the bub ble is cen tral the plat -
form is level and the plat form can be safely raised.
■ Hydraulic Oil Level
Figure 4.3 - Hydraulic Oil Level
The hydraulic oil level gauge is on the side of the
hydraulic oil tank. It shows the actual level of oil
inside the tank. Read it only when the booms are
fully lowered and stabilisers are raised in the travel
position. The oil level should be within + or - 6mm
(1/4”) of the line.
