■ Self Levelling Stabilizers (Option)

1.

Auto / Manual Switch:

Select either A or M

for automatic or manual operation of the
stabilizers.

2.

Auto Raise / Lower Switch:

Select either up

or down to raise or lower the stabilizers
automatically.

3.

Manual Stabilizer Switches:

When manual

is selected on switch 1 the stabilizers can be
individually raised and lowered manually with
these switches.

page 6 - 6

MHP12/34J – 11447A

6. Controls
