3. Specifications
The Snor kel MHP12/34J is a boom sup ported el e vat ing work plat form built to con form to all ap pli ca ble
OSHA, ANSI or CSA stan dards as pre vi ously out lined.
OSHA Para graph 1910.67 Ti tle 29, C.F.R., Ve hi cle-Mounted El e vating and Ro tating Work Plat forms - La -
bour.
OSHA Para graph 1926.556 Ti tle 29, C.F.R., Ae rial Lifts - Con struc tion.
Aus tra lian Stan dard AS1418-10 1996 El e vating Work Plat forms.
■ General Specifications
SPECIFICATIONS
MHP12/34J
Nominal working height
12.4m
40’ 8”
Maximum height to basket floor
10.4m
34’ 1”
Maximum outreach
5.4m
17’ 9”
Maximum outreach height
5.65m
18’ 6”
Maximum width of base
Outriggers retracted
Outriggers extended
1.55m
3.50m
5’ 1”
11’ 5”
Safe working load (unrestricted)
200kg
440lbs
Standard colour
Orange base/boom grey platform
Platform size
1200 x 760 x 1100mm
Aluminum
4’ x 2’ 6” x 3’ 7”
Aluminum
Travelling height
2.04m
6’ 8”
Overall length
5.71m
18’ 8”
Maximum towing speed
80km/h
50m/h
Turntable rotation
550 degrees non-continuous
Trailer tongue weight
75kg
165lbs
Maximum rated axle capacity
1200kg
2645lbs
Insulation rating
Nil
Weight
1160kg
2609lbs
MHP12/34J – 11447A
page 3 - 1
